Home ProductsAluminum Diamond Plate

5 Bar Tread Plate Aluminum Plate

5 Bar Tread Plate Aluminum Plate

    • 5 Bar Tread Plate Aluminum Plate
    • 5 Bar Tread Plate Aluminum Plate
    • 5 Bar Tread Plate Aluminum Plate
  • 5 Bar Tread Plate Aluminum Plate

    Product Details:

    Place of Origin: CHINA
    Brand Name: OEM
    Certification: ISO/SGS

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiation
    Price: Negotiation
    Packaging Details: Wooden cases standard export package
    Delivery Time: 7-14 days
    Payment Terms: T/T, L/C, T/T, Western Union
    Supply Ability: 1000 Ton per Month
    Contact Now
    Detailed Product Description
    Name: 5 Bar Aluminium Checker Plate Processing Service: Big 5 Bar Pattern, Bright Small 5 Bar, Diamond Plate, 2 Bar, 3 Bar
    Alloy Or Not: Is Alloy Type: Sheet, Coil
    Alloy No: 1100 1050 3003 3004 5052 5083 5754 6061 6082 6063 Surface Treatment: Embossed
    Application: Graphic Design, Antiskid, Etc. Width: 900mm-1650mm
    Color: Silver Or As Required Grade: 1000 3000 5000 6000 Series
    Tolerance: Thickness ±3% Temper: HO, H114, H12/H22, T6
    High Light:

    5 Bar Aluminium Checker Plate

    ,

    5 Bar Aluminum Tread Plate

    ,

    Diamond Plate Aluminum Sheets

    5 Bar Tread Plate Aluminum Plate


    Alloy/Grade
    1000 3000 5000 6000 series
    Temper
    HO, H12, H22, H114, T6 etc.
    Thickness
    1.2mm-8.0mm
    Width
    900mm-1650mm
    Rolling Material
    DC & CC route material
    Other Alloy
    1100 1050 3003 3004 5052 5083 5754 6061 6082 6063
    Pattern
    Big 5 bar pattern, Small brighten 5 bar, Diamond plate, 2 bar, Small 3 bar, etc.
    Surface
    Embossed Brighten Surface
    Standard
    GB/T, ASTM, EN
    Certificates
    ISO, SGS
    MOQ
    5 MT-8MT for Customized Production of each size, excluding stock
    Packaging
    Paper-interleaf each sheet+Water-proof Film+Wooden Pallets
    Delivery
    15-20 days for CC route; 20-25 days for DC route production
    Delivery Methods
    1. Truck+Sea----Any port of China; 2. River+Sea----Shanghai port, China; 3. Railway+Sea----Qinzhou port, China; 4. Railway---Chongqing-Sinkiang-Europe International Railway
    Application
    Platform, Anti skid Footboard for Bus, Fire-fighting Truck, Roofs,Ceilings, Decoration etc.
    Further Fabrication
    Suitable for Further Fabrication: 90 Degree Bending, Anodization, Cutting.
    Our Advantage
    No oil stain, no scratches, quite flatness; High Brightness; Plump and Uniform Pattern



    Bar Thickness
    Bottom Thickness
    Bar Thickness
    1.2 mm-1.4 mm
    0.4 mm-0.6 mm
    1.4 mm-1.9 mm
    0.8 mm-1.0 mm
    1.9 mm-3.5 mm
    1.0 mm-1.2 mm
    3.5mm-8.0 mm
    1.2mm and up


    5 Bar Tread Plate Aluminum Plate 0
